Product CatalogPart Number
PTRH-1A-24S-T4-XA
Manufacturer
Picker ComponentsDescription
RELAY GEN PURPOSE SPST 30A 24V
Datasheet
DatasheetPackage
-
In Stock
72,194 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PTRH-1A-24S-T4-XA
PTRH-1A-24S-T4-XA
lmages are for reference only.Payment Methods
Delivery Services
General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Chassis Mount
Quick Inquiry
PTRH-1A-24S-T4-XA
Specifications
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | Picker Components |
| Series | PTRH |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Chassis Mount |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 30 A |
| Switching Voltage | 300VAC, 110VDC - Max |
| Load - Max Switching | 9000VA, 3300W |
| Coil Current | 37.5 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Quick Connect - Multiple Sizes |
| Seal Rating | Sealed - Fully |
| Coil Insulation | Class B |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 15 ms |
| Release Time | 10 ms |
| Operating Temperature | -55°C ~ 100°C |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Approval Agency | CUL, cURus, UL |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 640 Ohms |
| Base Product Number | PTRH-1A |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | PTRH-1A-12SF-X | PTRH-1A-24S-1-X | PT22A012B | PT22A024B |
| Manufacturer | Picker Components | Picker Components | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | RELAY GEN PURPOSE SPST 30A 12V | RELAY GEN PURPOSE SPST 30A 24V | RELAY GEN PURPOSE DPDT 12A 12V | RELAY GEN PURPOSE DPDT 12A 24V |
| Series | Picker Components | Picker Components | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays |
| Packaging | Tube | Tube | Bulk | Bulk |
