PTVA082407NF-V1-R5
lmages are for reference only.PTVA082407NF-V1-R5
RF MOSFET LDMOS 48V 4HBSOF
DatasheetHBSOF-4-1
50,504 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Mosfet 48 V 900 mA 746MHz ~ 821MHz 20.5dB 225W PG-HBSOF-4-1
PTVA082407NF-V1-R5
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | MACOM Technology Solutions |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Technology | LDMOS |
| Configuration | - |
| Frequency | 746MHz ~ 821MHz |
| Gain | 20.5dB |
| Voltage - Test | 48 V |
| Current Rating (Amps) | 10µA |
| Noise Figure | - |
| Current - Test | 900 mA |
| Power - Output | 225W |
| Voltage - Rated | 105 V |
| Mounting Type | Surface Mount |
| Package / Case | HBSOF-4-1 |
| Supplier Device Package | PG-HBSOF-4-1 |
| Base Product Number | PTVA082407 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | PTVA082407NF-V2-R5 | PTVA030121EA-V1-R0 | PTVA030121EA-V1-R250 | PTVA030121EAV1XWSA1 |
| Manufacturer | MACOM Technology Solutions | MACOM Technology Solutions | MACOM Technology Solutions | Infineon Technologies |
| RoHS Status | RoHS Compliant | RoHS Compliant | ||
| Description | RF MOSFET LDMOS 48V 4HBSOF | RF MOSFET LDMOS 50V H-36265-2 | RF MOSFET LDMOS | RF MOSFET LDMOS H-36265-2 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tray |
