Product CatalogPart Number
RT8555BWSC
Manufacturer
Richtek USA Inc.Description
IC LED DRV RGLTR PWM 20WLCSP
Datasheet
DatasheetPackage
20-UFBGA, WLCSP
In Stock
10,838 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
RT8555BWSC
RT8555BWSC
lmages are for reference only.Payment Methods
Delivery Services
LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 35mA 20-WLCSP (1.65x2.05)
Quick Inquiry
RT8555BWSC
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Richtek USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | Yes |
| Number of Outputs | 6 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 24V |
| Voltage - Output | 36V |
| Current - Output / Channel | 35mA |
| Frequency | 300kHz ~ 2MHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 20-UFBGA, WLCSP |
| Supplier Device Package | 20-WLCSP (1.65x2.05) |
| Base Product Number | RT8555 |
| Grade | - |
| Qualification | - |
