Product CatalogPart Number
RT9715CGQW
Manufacturer
Richtek USA Inc.Description
IC PWR SWITCH N-CHAN 1:1 8WDFN
Datasheet
DatasheetPackage
8-WDFN Exposed Pad
In Stock
10,055 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
RT9715CGQW
RT9715CGQW
lmages are for reference only.Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 1.5A 8-WDFN (3x3)
Quick Inquiry
RT9715CGQW
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Richtek USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | USB Switch |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 1.5A |
| Rds On (Typ) | 90mOhm |
| Input Type | Non-Inverting |
| Features | Load Discharge, Status Flag |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-WDFN (3x3) |
| Package / Case | 8-WDFN Exposed Pad |
| Base Product Number | RT9715 |
| Grade | - |
| Qualification | - |
