RTQ2158GQWTF-QA
lmages are for reference only.RTQ2158GQWTF-QA
IC REG BUCK ADJ 8A 21WQFN
Datasheet21-WFQFN Exposed Pad
97,606 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 8A 21-WFQFN Exposed Pad
RTQ2158GQWTF-QA
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Richtek USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.85V |
| Voltage - Input (Max) | 6.5V |
| Voltage - Output (Min/Fixed) | 0.6V |
| Voltage - Output (Max) | 6.5V |
| Current - Output | 8A |
| Frequency - Switching | 2.1MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount, Wettable Flank |
| Package / Case | 21-WFQFN Exposed Pad |
| Supplier Device Package | 21-WQFN (4x4) |
| Base Product Number | RTQ2158 |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute |  |
 |
 |
 |
| Part Number | RTQ2102AGQW-QA | RTQ2103AGSP-QA | RTQ2104BGSP-QA | RTQ2104BPGSP-QA |
| Manufacturer | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BUCK ADJ 1.5A 8WDFN | IC REG BUCK ADJ 2A 8SOP | IC REG BUCK ADJ 3A 8SOP | IC REG BUCK ADJ 3A 8SOP |
| Series | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. | Richtek USA Inc. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
