SH50F-1.4-220
lmages are for reference only.SH50F-1.4-220
FIXED IND 220UH 1.4A 380 MOHM TH
DatasheetRadial, Vertical Cylinder, 4 Leads
37,541 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
220 µH Unshielded Toroidal Inductor 1.4 A 380mOhm Max Radial, Vertical Cylinder, 4 Leads
SH50F-1.4-220
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Amgis, LLC |
| Series | SH50 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 220 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 1.4 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 380mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder, 4 Leads |
| Supplier Device Package | - |
| Size / Dimension | 0.669" Dia (17.00mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
|
| Part Number | SH50B-0.42-2200 | SH50B-0.42-2200 | SH50B-0.62-1500 | SH50B-0.62-1500 |
| Manufacturer | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 2.2MH 420MA 1.8 OHM TH | FIXED IND 2.2MH 420MA 1.8 OHM TH | FIXED IND 1.5MH 620MA 1 OHM TH | FIXED IND 1.5MH 620MA 1 OHM TH |
| Series | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| Packaging | Tray | Tray | Tray | Tray |
