SI2302ADS-T1
lmages are for reference only.SI2302ADS-T1
MOSFET N-CH 20V 2.1A SOT23-3
DatasheetTO-236-3, SC-59, SOT-23-3
77,063 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 20 V 2.1A (Ta) 700mW (Ta) Surface Mount SOT-23-3 (TO-236)
SI2302ADS-T1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 2.1A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Rds On (Max) @ Id, Vgs | 60mOhm @ 3.6A, 4.5V |
| Vgs(th) (Max) @ Id | 1.2V @ 50µA |
| Vgs (Max) | ±8V |
| Input Capacitance (Ciss) (Max) @ Vds | 300 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 700mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-3 (TO-236) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | SI2302 |
| Gate Charge (Qg) (Max) @ Vgs | 10 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | SI2302ADS-T1-E3 | SI2302ADS-T1-GE3 | SI2302-TP | SI2302A |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Micro Commercial Co | UMW |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 20V 2.1A SOT23-3 | MOSFET N-CH 20V 2.1A SOT23-3 | MOSFET N-CH 20V 3A SOT-23 | 20V 2.8A 1.25W 115MR@2.5V,3.1A 1 |
| Series | - | - | - | UMW |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
