Product CatalogPart Number
SM24BHE3-TP
Manufacturer
Micro Commercial CoDescription
ESD,24V,SOT-23
Datasheet
DatasheetPackage
TO-236-3, SC-59, SOT-23-3
In Stock
81,489 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SM24BHE3-TP
SM24BHE3-TP
lmages are for reference only.Payment Methods
Delivery Services
50V Clamp 4A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23
Quick Inquiry
SM24BHE3-TP
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 2 |
| Voltage - Reverse Standoff (Typ) | 24V (Max) |
| Voltage - Breakdown (Min) | 27V |
| Voltage - Clamping (Max) @ Ipp | 50V |
| Current - Peak Pulse (10/1000µs) | 4A (8/20µs) |
| Power - Peak Pulse | 300W |
| Power Line Protection | No |
| Applications | - |
| Capacitance @ Frequency | 15pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23 |
| Base Product Number | SM24 |
| Unidirectional Channels | - |
| Grade | Automotive |
| Qualification | AEC-Q101 |
