SN74AHC05N
lmages are for reference only.SN74AHC05N
IC INVERTER 6CH 1-INP 14DIP
Datasheet14-DIP (0.300", 7.62mm)
16,468 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Inverter IC 6 Channel Open Drain 14-PDIP
SN74AHC05N
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Texas Instruments |
| Series | 74AHC |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | 74AHC05 |
| Logic Type | Inverter |
| Number of Circuits | 6 |
| Number of Inputs | 1 |
| Features | Open Drain |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Quiescent (Max) | 2 μA |
| Current - Output High, Low | -, 8mA |
| Input Logic Level - Low | 0.5V ~ 1.65V |
| Input Logic Level - High | 1.5V ~ 3.85V |
| Max Propagation Delay @ V, Max CL | 7.5ns @ 5V, 50pF |
| Operating Temperature | -40＜C ~ 85＜C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-PDIP |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SN74AHC05D | SN74AHC05DBR | SN74AHC05DR | SN74AHC05NS |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | Not applicable |
| Description | IC INVERTER 6CH 1-INP 14SOIC | IC INVERTER 6CH 1-INP 14SSOP | IC INVERTER 6CH 1-INP 14SOIC | IC BUFFER/DRIVER INV 6-CH |
| Series | 74AHC | 74AHC | 74AHC | * |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
