STGWT20IH125DF
lmages are for reference only.STGWT20IH125DF
IGBT TRENCH FS 1250V 40A TO3P
DatasheetTO-3P-3, SC-65-3
49,752 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Trench Field Stop 1250 V 40 A 259 W Through Hole TO-3P
STGWT20IH125DF
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 1250 V |
| Current - Collector (Ic) (Max) | 40 A |
| Current - Collector Pulsed (Icm) | 80 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 15A |
| Power - Max | 259 W |
| Switching Energy | 410µJ (off) |
| Input Type | Standard |
| Gate Charge | 68 nC |
| Td (on/off) @ 25°C | -/106ns |
| Test Condition | 600V, 15A, 10Ohm, 15V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-3P-3, SC-65-3 |
| Supplier Device Package | TO-3P |
| Reverse Recovery Time (trr) | - |
| Base Product Number | STGWT20 |
| Product Attribute |  |
 |
|
 |
| Part Number | STGW100H65FB2-4 | STGW10M65DF2 | STGW15H120DF2 | STGW15H120F2 |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TRENCH GATE FIELD-STOP, 650 V, 1 | TRENCH GATE FIELD-STOP IGBT M SE | IGBT H-SERIES 1200V 15A TO-247 | IGBT H-SERIES 1200V 15A TO-247 |
| Series | HB2 | M | - | - |
| Packaging | Tube | Tube | Tube | Tube |
