TMPG06-20HE3/53
lmages are for reference only.TMPG06-20HE3/53
TVS DIODE 16.2VWM 29.1VC MPG06
DatasheetMPG06, Axial
95,428 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
29.1V Clamp 13.7A Ipp Tvs Diode Through Hole MPG06
TMPG06-20HE3/53
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Series | PAR® |
| Packaging | Tape & Box (TB) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 16.2V |
| Voltage - Breakdown (Min) | 18V |
| Voltage - Clamping (Max) @ Ipp | 29.1V |
| Current - Peak Pulse (10/1000µs) | 13.7A |
| Power - Peak Pulse | 400W |
| Power Line Protection | No |
| Applications | - |
| Capacitance @ Frequency | - |
| Operating Temperature | -65°C ~ 185°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | MPG06, Axial |
| Supplier Device Package | MPG06 |
| Base Product Number | TMPG06 |
| Unidirectional Channels | 1 |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
|
| Part Number | TMPG06-20HE3/54 | TMPG06-20HE3/73 | TMPG06-20-1HE3_A/B | TMPG06-20-81HE3/53 |
| Manufacturer | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TVS DIODE 16.2VWM 29.1VC MPG06 | TVS DIODE 16.2VWM 29.1VC MPG06 | TVS DIODE AXIAL | TVS DIODE MPG06 |
| Series | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division | Vishay General Semiconductor - Diodes Division |
| Packaging | Tape & Reel (TR) | Tape & Box (TB) | Tape & Reel (TR) | Tape & Box (TB) |
