Linear Voltage Regulator IC Positive Adjustable 1 Output 3A 8-ESOP
TPL6305AD-ES1R-S
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | 3PEAK |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 6.5V |
| Voltage - Output (Min/Fixed) | 0.5V |
| Voltage - Output (Max) | 5.2V |
| Voltage Dropout (Max) | 0.3V @ 3A |
| Current - Output | 3A |
| Current - Quiescent (Iq) | 15 mA |
| PSRR | 63dB ~ 35dB (1kHz ~ 100kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 8-ESOP |
| Base Product Number | - |
| Current - Supply (Max) | 15 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | TPL6305AD-ES1R | TPS79628DCQ | TPS79318DBVTG4 | TPS70618DRVR |
| Manufacturer | 3PEAK | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LOW-DROPOUT LINEAR REGULATOR 8-E | IC REG LINEAR 2.8V 1A SOT223-6 | IC REG LINEAR 1.8V 200MA SOT23-5 | IC REG LINEAR 1.8V 150MA 6WSON |
| Series | 3PEAK | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
