TPW3188Q-TS3R-S
lmages are for reference only.Payment Methods
Delivery Services
1 Circuit IC Switch 8:1 270Ohm 16-TSSOP
TPW3188Q-TS3R-S
| Category | Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
| Manufacturer | 3PEAK |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Switch Circuit | SP8T - Open |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 270Ohm |
| Channel-to-Channel Matching (ΔRon) | 1Ohm |
| Voltage - Supply, Single (V+) | 1.65V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 37ns, 45ns |
| -3db Bandwidth | 250MHz |
| Charge Injection | 15pC |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 14pF |
| Current - Leakage (IS(off)) (Max) | 800nA |
| Crosstalk | -90dB @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute | |
 |
|
 |
| Part Number | TPW3188Q-TS3R-S | TPW3111-S5TR | TPW3111-S5TR | TPW3115-S5TR |
| Manufacturer | 3PEAK | 3PEAK | 3PEAK | 3PEAK |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | AUTOMOTIVE GRADE, 5V 8:1 ANALOG | ANALOG SWITCH SPDT (SINGLEPOLE D | ANALOG SWITCH SPDT (SINGLEPOLE D | ANALOG SWITCH SPDT (SINGLEPOLE D |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
