UC1524AJ
lmages are for reference only.UC1524AJ
ADVANCED 40 VCC, DOUBLE ENDED 30
Datasheet16-CDIP (0.300", 7.62mm)
44,228 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Down DC-DC Controller IC 16-CDIP
UC1524AJ
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Type | PWM |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull |
| Number of Outputs | 2 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 8V ~ 40V |
| Frequency - Switching | 140Hz ~ 500kHz |
| Duty Cycle (Max) | 45% |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Enable, Frequency Control, Ramp |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CDIP |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UC1524AL883B | UC1525AJ | UC1526AJ/80516 | UC1526J |
| Manufacturer | Texas Instruments | Texas Instruments | Unitrode | Texas Instruments |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | Not applicable | ROHS3 Compliant |
| Description | UC1524A ADVANCED REGULATING PULS | REGULATING PULSE WIDTH MODULATOR | SWITCHING CONTROLLER, VOLTAGE-MO | REGULATING PULSE WIDTH MODULATOR |
| Series | - | - | - | - |
| Packaging | Bulk | Tube | Bulk | Tube |
