ULN2003APWG4
lmages are for reference only.ULN2003APWG4
IC PWR RELAY 7NPN 1:1 16TSSOP
Datasheet16-TSSOP (0.173", 4.40mm Width)
69,663 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Switch/Driver 1:1 Darlington 500mA 16-TSSOP
ULN2003APWG4
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | Texas Instruments |
| Series | ULx200xA |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Switch Type | Relay, Solenoid Driver |
| Number of Outputs | 7 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | Low Side |
| Output Type | Darlington |
| Interface | Parallel |
| Voltage - Load | 50V (Max) |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 500mA |
| Rds On (Typ) | - |
| Input Type | Inverting |
| Features | - |
| Fault Protection | - |
| Operating Temperature | -40°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 16-TSSOP |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Base Product Number | ULN2003 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | ULN2003APG,CN | ULN2003APW | ULN2003APWR | ULN2003APWR |
| Manufacturer | Toshiba Semiconductor and Storage | Texas Instruments | Texas Instruments | UMW |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC PWR RELAY 7NPN 1:1 16DIP | TRAN 7NPN DARL 50V 0.5A 16TSSOP | TRAN 7NPN DARL 50V 0.5A 16TSSOP | TRAN 7NPN DARL 50V 0.5A 16TSSOP |
| Series | Toshiba Semiconductor and Storage | Texas Instruments | Texas Instruments | UMW |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
