URB2403S-10WR3
lmages are for reference only.URB2403S-10WR3
DC DC CONVERTER 3.3V 7.9W
Datasheet8-SIP Module, 7 Leads
50,053 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 3.3V 2.4A 9V - 36V Input
URB2403S-10WR3
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Mornsun America, LLC |
| Series | |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 3.3V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 2.4A |
| Power (Watts) | 7.9 W |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 85% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 8-SIP Module, 7 Leads |
| Size / Dimension | 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | CE |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | 1.5 kV |
| Product Attribute |  |
 |
 |
 |
| Part Number | URB2403S-6WR3 | URB2403JD-15W | URB2403JD-3W | URB2403JMD-15W |
| Manufacturer | Mornsun America, LLC | Mornsun America, LLC | Mornsun America, LLC | Mornsun America, LLC |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ||
| Description | DC DC CONVERTER 3.3V 4.5W | DC DC CONVERTER 3.3V 15W | DC DC CONVERTER 3.3V 3W | DC DC CONVERTER 3.3V 15W |
| Series | ||||
| Packaging | URB2403S-6WR3 (6W) | URB2403JD-15W (15W) | URB2403JD-3W (3W) | URB2403JMD-15W (15W) |
