Product CatalogPart Number
XDMYK14A
Manufacturer
SunLEDDescription
DISPLAY 7SEG 0.56" SGL YLW 10DIP
Datasheet
DatasheetPackage
10-DIP (0.600", 15.24mm)
In Stock
59,235 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XDMYK14A
XDMYK14A
lmages are for reference only.Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Yellow 7-Segment 1 Character Common Anode 1.95V 10mA 0.750" H x 0.500" W x 0.315" D (19.05mm x 12.70mm x 8.00mm) 10-DIP (0.600", 15.24mm)
Quick Inquiry
XDMYK14A
Specifications
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | SunLED |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Number of Characters | 1 |
| Size / Dimension | 0.750" H x 0.500" W x 0.315" D (19.05mm x 12.70mm x 8.00mm) |
| Digit/Alpha Size | 0.56" (14.22mm) |
| Display Type | 7-Segment |
| Common Pin | Common Anode |
| Color | Yellow |
| Voltage - Forward (Vf) (Typ) | 1.95V |
| Current - Test | 10mA |
| Millicandela Rating | 48mcd |
| Wavelength - Peak | 590nm |
| Power Dissipation (Max) | 75mW |
| Package / Case | 10-DIP (0.600", 15.24mm) |
| Base Product Number | XDMYK14 |
| Display Format | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | XDMYK14A2 | XDMYK14A3 | XDMYK14C | XDMYK14C2 |
| Manufacturer | SunLED | SunLED | SunLED | SunLED |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DISPLAY 7SEG 0.56" DBL YLW 10DIP | DISPLAY 7SEG 0.56" TRP YLW 10DIP | DISPLAY 7SEG 0.56" SGL YLW 10DIP | DISPLAY 7SEG 0.56" DBL YLW 18DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
