ZX75BP-2150-S+
lmages are for reference only.ZX75BP-2150-S+
RF FILT BAND PASS 2.15GHZ INLINE
DatasheetInline, SMA Connection, F and M
56,177 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.15GHz Center Frequency Band Pass RF Filter (Radio Frequency) 200MHz Bandwidth 2dB Inline, SMA Connection, F and M
ZX75BP-2150-S+
| Category | Filters - RF Filters - |
| Manufacturer | Mini-Circuits |
| Series | ZX75BP |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Frequency | 2.15GHz Center |
| Bandwidth | 200MHz |
| Filter Type | Band Pass |
| Ripple | - |
| Insertion Loss | 2dB |
| Mounting Type | Free Hanging (In-Line) |
| Package / Case | Inline, SMA Connection, F and M |
| Size / Dimension | 0.740" L x 0.750" W (18.80mm x 19.05mm) |
| Height (Max) | 0.490" (12.45mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ZX75BP-204-S+ | ZX75BP-2250-S+ | ZX75-12-S+ | ZX75-12M-S+ |
| Manufacturer | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RF FILTER BANDPASS 206MHZ INLINE | RF FILTER BAND PASS 2.25GHZ MOD | RF FILTER BAND PASS 12MHZ INLINE | RF FILTER BAND PASS 12MHZ INLINE |
| Series | ZX75BP | ZX75BP | ZX75 | ZX75 |
| Packaging | Tray | Tray | Tray | Tray |
