1-1618256-3
lmages are for reference only.1-1618256-3
RELAY GEN PURPOSE SPST 10A 12V
Datasheet-
33,741 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay SPST-NC (1 Form B) 12VDC Coil Panel Mount
1-1618256-3
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | PD10, KILOVAC |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Panel Mount |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NC (1 Form B) |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 320VDC - Max |
| Load - Max Switching | 3200VA |
| Coil Current | 171.4 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Vacuum |
| Coil Insulation | - |
| Must Operate Voltage | 8 VDC |
| Must Release Voltage | 6 VDC |
| Operate Time | 10 ms |
| Release Time | 10 ms |
| Operating Temperature | -35°C ~ 65°C |
| Contact Material | - |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 70 Ohms |
| Base Product Number | PD10B3 |
| Product Attribute | |
|
|
|
| Part Number | 1-1618256-2 | 1-1616082-0 | 1-1616109-6 | 1-1616109-7 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | PD10B235=RELAY, VACUUM, SPST-N | A885Y=RELAY | A711JF=RELAY | A711JM=RELAY |
| Series | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| Packaging | Bulk | Bulk | Bulk | Bulk |
