2ED2110S06MXUMA1
lmages are for reference only.2ED2110S06MXUMA1
IC GATE DRVR HI/LOW SIDE 16SOIC
Datasheet16-SOIC (0.295", 7.50mm Width)
29,128 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
High-Side and Low-Side Gate Driver IC Non-Inverting 16-SOIC
2ED2110S06MXUMA1
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | High-Side and Low-Side |
| Channel Type | Independent |
| Number of Drivers | 2 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 10V ~ 20V |
| Logic Voltage - VIL, VIH | 6V, 14V |
| Current - Peak Output (Source, Sink) | 2.5A, 2.5A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 650 V |
| Rise / Fall Time (Typ) | 25ns, 17ns |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | 2ED2110 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | 2SP0325T2A1-CM2500DY-24S | 2DU180506MR04 | 2EDN7534BXTSA1 | 2ED21084S06JXUMA1 |
| Manufacturer | Power Integrations | Tamura | Infineon Technologies | Infineon Technologies |
| RoHS Status | Request inventory verification | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE DRVR HALF-BRIDGE MODULE | IC GATE DRVR HALF-BRIDGE MODULE | IC GATE DRVR LOW-SIDE SOT23-6 | IC GATE DRVR HALF-BRIDGE 14SOIC |
| Series | SCALE™-2 | - | - | - |
| Packaging | Tray | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
