ECLAMP2504K.TCT
lmages are for reference only.ECLAMP2504K.TCT
FILTER LC(PI) 17NH/12PF ESD SMD
Datasheet8-UFDFN Exposed Pad
98,207 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC (Pi) EMI Filter 3rd Order Low Pass 4 Channel L = 17nH, C = 12pF 8-UFDFN Exposed Pad
ECLAMP2504K.TCT
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Semtech Corporation |
| Series | EMIClamp® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | 250MHz (Cutoff) |
| Attenuation Value | 20dB @ 800MHz ~ 2.7GHz |
| Resistance - Channel (Ohms) | 18 |
| Current | - |
| Values | L = 17nH, C = 12pF |
| ESD Protection | Yes |
| Operating Temperature | -40°C ~ 85°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-UFDFN Exposed Pad |
| Size / Dimension | 0.067" L x 0.051" W (1.70mm x 1.30mm) |
| Height | 0.022" (0.55mm) |
| Number of Channels | 4 |
| Base Product Number | ECLAMP2504 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | ECLAMP2504K.TCT | ECLAMP2506K.TCT | ECLAMP2506K.TCT | ECLAMP2508K.TCT |
| Manufacturer | Semtech Corporation | Semtech Corporation | Semtech Corporation | Semtech Corporation |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | FILTER LC(PI) 17NH/12PF ESD SMD | FILTER LC(PI) 17NH/12PF ESD SMD | FILTER LC(PI) 17NH/12PF ESD SMD | FILTER LC(PI) 17NH/12PF ESD SMD |
| Series | EMIClamp® | EMIClamp® | EMIClamp® | EMIClamp® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
