Product CatalogPart Number
HAX 500-S/SP11C
Manufacturer
LEM USA Inc.Description
TRANSDUCER
Datasheet
DatasheetPackage
Module, Single Pass Through
In Stock
99,731 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HAX 500-S/SP11C
HAX 500-S/SP11C
lmages are for reference only.Payment Methods
Delivery Services
Current Sensor 500A 1 Channel Hall Effect, Open Loop Bidirectional Module, Single Pass Through
Quick Inquiry
HAX 500-S/SP11C
Specifications
| Category | Sensors, Transducers - Current Sensors - |
| Manufacturer | LEM USA Inc. |
| Series | HAX |
| Packaging | Bulk |
| RoHS Status | |
| For Measuring | AC/DC |
| Sensor Type | Hall Effect, Open Loop |
| Current - Sensing | 500A |
| Number of Channels | 1 |
| Output | Analog Voltage |
| Sensitivity | - |
| Frequency | DC ~ 50kHz |
| Linearity | ±1% |
| Accuracy | ±1% |
| Voltage - Supply | ±15V |
| Response Time | 5µs |
| Current - Supply (Max) | 20mA |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Bidirectional |
| Mounting Type | Chassis Mount |
| Package / Case | Module, Single Pass Through |
| Supplier Device Package | - |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | HAX 500-S | HAX 5000-S | CSNF151-001 | CSLA1GF |
| Manufacturer | LEM USA Inc. | LEM USA Inc. | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | |
| Description | SENSOR CURRENT HALL 500A AC/DC | TRANSDUCER | SENSOR CURRENT HALL 180A AC/DC | SENSOR CURRENT HALL 100A AC/DC |
| Series | LEM USA Inc. | LEM USA Inc. | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions |
| Packaging | Bulk | Bulk | Bulk | Bulk |
