PCN10A-100P-2.54DS(72)
lmages are for reference only.PCN10A-100P-2.54DS(72)
CONN DIN HDR 100POS PCB RA GOLD
Datasheet-
95,496 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
100 Position Din Connector Header, Male Pins Gold Through Hole, Right Angle
PCN10A-100P-2.54DS(72)
| Category | Connectors, Interconnects - Backplane Connectors - DIN 41612 |
| Manufacturer | Hirose Electric Co Ltd |
| Series | PCN10 |
| Packaging | Tray |
| RoHS Status | RoHS Compliant |
| Connector Type | Header, Male Pins |
| Number of Positions | 100 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Style | - |
| Level, Class | - |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 8.00µin (0.203µm) |
| Operating Temperature | -55°C ~ 85°C |
| Current Rating (Amps) | 2A |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Base Product Number | PCN10 |
| Product Attribute | .jpg "PCN10A-128P-2.54DS(72)") |
 |
.jpg "PCN10A-16P-2.54DS(72)") |
 |
| Part Number | PCN10A-128P-2.54DS(72) | PCN10A-128P-2.54DS(77) | PCN10A-16P-2.54DS(72) | PCN10A-20P-2.54DS |
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | CONN DIN HDR 128POS PCB RA GOLD | CONN DIN HDR 128POS PCB RA GOLD | CONN DIN HDR 16POS PCB RA GOLD | CONN DIN HDR 20POS PCB RA GOLD |
| Series | PCN10 | PCN10 | PCN10 | PCN10 |
| Packaging | Tray | Tray | Tray | Bulk |
