SN54LS273J
lmages are for reference only.SN54LS273J
OCTAL D-TYPE FLIP-FLOP WITH CLEA
Datasheet20-CDIP (0.300", 7.62mm)
63,395 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-CDIP (0.300", 7.62mm)
SN54LS273J
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | Texas Instruments |
| Series | 54LS |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Master Reset |
| Type | D-Type |
| Output Type | Non-Inverted |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Clock Frequency | 40 MHz |
| Max Propagation Delay @ V, Max CL | 27ns @ 5V, 15pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 400µA, 4mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Iq) | 27 mA |
| Input Capacitance | - |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 20-CDIP |
| Package / Case | 20-CDIP (0.300", 7.62mm) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SN54107J | SN5472J | SN5476J | SN54ALS109AJ |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | 54107 DUAL J-K FLIP-FLOPS WITH C | AND-GATED J-K MASTER-SLAVE FLIP- | DUAL J-K FLIP-FLOPS WITH PRESET | 54ALS109A DUAL J-K POSITIVE-EDGE |
| Series | * | - | - | * |
| Packaging | Bulk | Tube | Tube | Bulk |
