SN54LS76AJ
lmages are for reference only.SN54LS76AJ
DUAL J-K FLIP-FLOPS WITH PRESET
Datasheet16-CDIP (0.300", 7.62mm)
99,147 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 2 Element JK Type 1 Bit Negative Edge 16-CDIP (0.300", 7.62mm)
SN54LS76AJ
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | Texas Instruments |
| Series | 54LS |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Output Type | Complementary |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Clock Frequency | 45 MHz |
| Max Propagation Delay @ V, Max CL | 20ns @ 5V, 15pF |
| Trigger Type | Negative Edge |
| Current - Output High, Low | 4mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Iq) | 6 mA |
| Input Capacitance | - |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 16-CDIP |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SN54LS73AJ | SN54LS74AJ | SN54107J | SN5472J |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | DUAL J-K FLIP-FLOPS WITH CLEAR A | DUAL D-TYPE POSITIVE-EDGE-TRIGGE | 54107 DUAL J-K FLIP-FLOPS WITH C | AND-GATED J-K MASTER-SLAVE FLIP- |
| Series | 54LS | 54LS | * | - |
| Packaging | Tube | Tube | Bulk | Tube |
