SPNH125.XXDEMS
lmages are for reference only.SPNH125.XXDEMS
1500VDC 125 AMP PV FUSE W/MS INT
DatasheetRectangular, Blade
60,780 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
125A 1.5 kVDC Fuse Rectangular Bolt Mount
SPNH125.XXDEMS
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Littelfuse Inc. |
| Series | POWR-GARD® SPNH |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Bolt Mount |
| Fuse Type | Rectangular |
| Current Rating (Amps) | 125A |
| Voltage Rating - AC | - |
| Response Time | Fast Blow |
| Applications | Solar (Photovoltaic) |
| Features | - |
| Class | - |
| Approval Agency | CE, gPV, IEC, UL |
| Operating Temperature | - |
| Breaking Capacity @ Rated Voltage | 30kA |
| Package / Case | Rectangular, Blade |
| Size / Dimension | 5.165" L x 2.008" W x 2.008" H (131.20mm x 51.00mm x 51.00mm) |
| Base Product Number | - |
| Voltage Rating - DC | 1.5 kVDC |
| Grade | - |
| Qualification | - |
| Melting I²t | 15000.0 |
| DC Cold Resistance | 0.00107 Ohms |
| Product Attribute |  |
 |
 |
 |
| Part Number | SPNH125.XXDE | SPNH125.XXDL | SPNH125.XXDLMS | SPNH050.X |
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 1500VDC 125 AMP PHOTOVOLTAIC FUS | 1500VDC 125 AMP PHOTOVOLTAIC FUS | 1500VDC 125 AMP PV FUSE W/MS INT | 1500VDC 50 AMP PHOTOVOLTAIC FUSE |
| Series | POWR-GARD® SPNH | POWR-GARD® SPNH | POWR-GARD® SPNH | POWR-GARD® SPNH |
| Packaging | Box | Box | Box | Box |
