TB6561NG,8
lmages are for reference only.TB6561NG,8
IC MOTOR DRIVER 10V-36V 24SDIP
Datasheet24-SDIP (0.300", 7.62mm)
45,299 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Motor Driver Bi-CMOS PWM 24-SDIP
TB6561NG,8
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (4) |
| Interface | PWM |
| Technology | Bi-CMOS |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1.5A |
| Voltage - Supply | 10V ~ 36V |
| Voltage - Load | 10V ~ 36V |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 24-SDIP (0.300", 7.62mm) |
| Supplier Device Package | 24-SDIP |
| Base Product Number | TB6561 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
.jpg "TB6549FG(O,EL)") |
| Part Number | TB6561NG | TB6561NG | TB6561NG,8 | TB6549FG(O,EL) |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ||
| Description | IC MOTOR DRIVER 10V-36V 24SDIP | IC MOTOR DRIVER 10V-36V 24SDIP | IC MOTOR DRIVER 10V-36V 24SDIP | IC MOTOR DRIVER 10V-27V 20HSOP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tray | Tape & Reel (TR)-->Cut Tape (CT) |
