TB6562AFG,8,EL
lmages are for reference only.TB6562AFG,8,EL
IC MTR DRV BIPOLAR 10-34V 30SSOP
Datasheet30-BSOP (0.295", 7.50mm Width)
91,154 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar Motor Driver DMOS Parallel 30-SSOP
TB6562AFG,8,EL
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | - |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (4) |
| Interface | Parallel |
| Technology | DMOS |
| Step Resolution | 1, 1/2, 1/4 |
| Applications | General Purpose |
| Current - Output | 1.5A |
| Voltage - Supply | 10V ~ 34V |
| Voltage - Load | 10V ~ 34V |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 30-BSOP (0.295", 7.50mm Width) |
| Supplier Device Package | 30-SSOP |
| Base Product Number | TB6562 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
.jpg "TB6549FG(O,EL)") |
|
.jpg "TB6549HQ(O)") |
| Part Number | TB6562AFG,8,EL | TB6549FG(O,EL) | TB6549FG(O,EL) | TB6549HQ(O) |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | |
| Description | IC MTR DRV BIPOLAR 10-34V 30SSOP | IC MOTOR DRIVER 10V-27V 20HSOP | IC MOTOR DRIVER 10V-27V 20HSOP | IC MOTOR DRIVER 10V-27V 25HZIP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
