MOSFET N/P-CH 60V 24A 8PDFN
Datasheet8-PowerTDFN
32,181 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 60V 24A (Tc), 18A (Tc) 40W Surface Mount 8-PDFN (5x6)
TSM6502CR RLG
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | N and P-Channel |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 24A (Tc), 18A (Tc) |
| Rds On (Max) @ Id, Vgs | 34mOhm @ 5.4A, 10V, 68mOhm @ 4A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 10.3nC @ 4.5V, 9.5nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 1159pF @ 30V, 930pF @ 30V |
| Power - Max | 40W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerTDFN |
| Supplier Device Package | 8-PDFN (5x6) |
| Base Product Number | TSM6502 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TSM6502CR | TSM2537CQ RFG | TSM300NB06LDCR | TSM6968DCA RVG |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N/P-CH 60V 24A 8PDFN | MOSFET N/P-CH 20V 11.6A 6TDFN | MOSFET 2N-CH 60V 5A 8PDFNU | MOSFET 2N-CH 20V 6.5A 8TSSOP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
