Product CatalogPart Number
UP1966E
Manufacturer
EPCDescription
IC GATE DRVR HALF-BRIDGE 12WLCSP
Datasheet
DatasheetPackage
12-UFBGA, WLCSP
In Stock
72,941 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
UP1966E
UP1966E
lmages are for reference only.Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 12-WLCSP-B (1.6x1.6)
Quick Inquiry
UP1966E
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | EPC |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Half-Bridge |
| Channel Type | Independent |
| Number of Drivers | 2 |
| Gate Type | Enhanced Mode GaN FET |
| Voltage - Supply | 4.5V ~ 5.5V |
| Logic Voltage - VIL, VIH | 0.5V, 2.3V |
| Current - Peak Output (Source, Sink) | 7.1A, 12.5A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 85 V |
| Rise / Fall Time (Typ) | 8ns, 4ns |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 12-UFBGA, WLCSP |
| Supplier Device Package | 12-WLCSP-B (1.6x1.6) |
| Base Product Number | UP1966 |
| Grade | - |
| Qualification | - |
