XP8NA2R2CXT
Manufacturer
YAGEO XSEMIDescription
MOSFET N-CH 80V 35A 168A PMPAK
Datasheet
DatasheetPackage
8-PowerLDFN
In Stock
97,933 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
XP8NA2R2CXT
XP8NA2R2CXT
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 80 V 35A (Ta), 168A (Tc) 5W (Ta), 113.6W (Tc) Surface Mount PMPAK® 5 x 6
Quick Inquiry
XP8NA2R2CXT
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | YAGEO XSEMI |
| Series | XP8NA2R2C |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 80 V |
| Current - Continuous Drain (Id) @ 25°C | 35A (Ta), 168A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Rds On (Max) @ Id, Vgs | 2.2mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 9328 pF @ 60 V |
| FET Feature | - |
| Power Dissipation (Max) | 5W (Ta), 113.6W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PMPAK® 5 x 6 |
| Package / Case | 8-PowerLDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 179 nC @ 10 V |
| Grade | - |
| Qualification | - |
