BSC037N08NS5TATMA1
lmages are for reference only.BSC037N08NS5TATMA1
MOSFET N-CH 80V 22A/100A TDSON
Datasheet8-PowerTDFN
77,549 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 80 V 22A (Ta), 100A (Tc) 3W (Ta), 136W (Tc) Surface Mount PG-TDSON-8-7
BSC037N08NS5TATMA1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS™ 5 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 80 V |
| Current - Continuous Drain (Id) @ 25°C | 22A (Ta), 100A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Rds On (Max) @ Id, Vgs | 3.7mOhm @ 50A, 10V |
| Vgs(th) (Max) @ Id | 3.8V @ 72µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 4200 pF @ 40 V |
| FET Feature | - |
| Power Dissipation (Max) | 3W (Ta), 136W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TDSON-8-7 |
| Package / Case | 8-PowerTDFN |
| Base Product Number | BSC037 |
| Gate Charge (Qg) (Max) @ Vgs | 58 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
|
| Part Number | BSC037N025S G | BSC037N08NS5ATMA1 | BSC004NE2LS5ATMA1 | BSC005N03LS5ATMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | MOSFET N-CH 25V 21A/100A TDSON | MOSFET N-CH 80V 100A TDSON | TRENCH <= 40V | TRENCH <= 40V |
| Series | OptiMOS™ | OptiMOS™ | OptiMOS™ | OptiMOS™ |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
