UC1825L883B DM: 5962-87681012A
lmages are for reference only.UC1825L883B DM: 5962-87681012A
HIGH SPEED PWM CONTROLLER 20-LCC
Datasheet20-CLCC
46,477 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost, Flyback, Forward, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 20-LCCC (8.89x8.89)
UC1825L883B DM: 5962-87681012A
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Type | Transistor Driver |
| Function | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Boost, Flyback, Forward, Full-Bridge, Half-Bridge, Push-Pull |
| Number of Outputs | 2 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 30V |
| Frequency - Switching | 340kHz ~ 460kHz |
| Duty Cycle (Max) | 80% |
| Synchronous Rectifier | No |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Current Limit, Enable, Frequency Control, Ramp, Soft Start |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 20-CLCC |
| Supplier Device Package | 20-LCCC (8.89x8.89) |
| Base Product Number | UC1825 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | UC1524AJ | UC1524AL883B | UC1525AJ | UC1526AJ/80516 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Unitrode |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | Not applicable |
| Description | ADVANCED 40 VCC, DOUBLE ENDED 30 | UC1524A ADVANCED REGULATING PULS | REGULATING PULSE WIDTH MODULATOR | SWITCHING CONTROLLER, VOLTAGE-MO |
| Series | - | - | - | - |
| Packaging | Tube | Bulk | Tube | Bulk |
